S-3 Series Half Power Rack With Dual 105KG Weight Stack Cable System (75x75mm)

The Rival Strength S-3 Series Half Power Rack With Dual 105KG Weight Stack Cable System is designed for commercial use with an 11 gauge steel frame. This rack provides a fully equipped and expandable solution for your gym, with integrated dual action adjustable cable system and 2x 105KG Weight stacks.

With a wide range of attachments available, this rack allows the user to get the most out of their space while having a premium rack as the centre piece for performing all lifts.

The rack features a Multi-Grip Pull-Up Bar, 2x Sandwich J-Cups, 2x Spotter Arms, 2x Front Stabiliser feet, 2x Free Motion Swivel Arms with D-Handles and 8x Weight Plate Storage Poles.

The multi-grip pullup bar has a 32mm diameter, with the back horizontal bar being 50mm in diameter to give a more challenging grip option.

The cable system uses high quality silver aluminium pulley wheels with bearings, this provides a smooth frictionless motion when using the cables.

The cable system operates on a 2:1 ratio.

What are ratios?

A 2:1 Ratio means the weight being lifted is half the weight loaded onto the plate carriage or weight stack (40KG feels like 20KG), a 1:1 ratio you would be lifting the full weight loaded onto the carriage (40KG feels like 40KG). The benefit of a 2:1 ratio over a 1:1 ratio is the distance the handle can be pulled. The handle can move twice the distance compared to a 1:1 ratio, giving you more room for cable flies and any exercise that requires the cable to move further, while also offering smaller increments when adjusting the weight. This is especially important when performing exercise for rehabilitation where smaller jumps are needed and a lighter starting weight. Please get in touch if you have any questions on this, we would be happy assisting!

Product Details:

75x75x3mm box section uprights with 26.5mm holes, compatible with all attachments in our S-Series range.

2-Year Commercial Warranty

2x 105KG Weight Stacks

1x Multi-Grip Pull-Up Bar - 32mm and 50mm grip diameter

2x Sandwich J-Cups

2x Spotter Arms

2x Front Stabilisers

2x Free Motion Swivel Arms with D-Handles

8x Weight Plate Storage Poles

All cables run on high quality aluminium pulley wheels for smooth operation

Powder coated in a matte black finish

1" Diameter holes spaced at 50mm intervals

75x75x3mm 11 gauge steel frame

Can be bolted to the floor

Modular design, with a wide range of accessories available

Specification:

Frame: 75mm x 75mm x 3mm

Height: 2280mm

Rack width (outside of uprights): 1200mm

Rack total width (including storage poles): 1925mm

Rack total depth (including front stabiliser): 1375mm

Load capacity: 500KG
